Model | 5 KWH | 10KWH | 15KWH | 20KWH |
Battery Type | LiFePO₄ | LiFePO₄ | LiFePO₄ | LiFePO₄ |
Battery Module QTY(pcs) | 1PCS | 2PCS | 3PCS | 4PCS |
Normal Capacity QTY(25℃,0.2C) | 5 kwh | 10 kwh | 15kwh | 20kwh |
Rating voltage | 51.2 V | 51.2 V | 51.2 V | 51.2 V |
Full charging voltage | 58.4 V | 58.4 V | 58.4 V | 58.4 V |
Discharging stop voltage | 41.6 V | 41.6 V | 41.6 V | 41.6 V |
Max charging current | 100 A | 100 A | 100 A | 100 A |
MAX Discharging current | 100 A | 100 A | 100 A | 100 A |
Cycle life | 6000 | |||
Communication PORT | RS485/CAN/RS232 | |||
PROTECTION | ||||
Protection | Overcharge protection,Overdischarge protection,over load protection | |||
working Temperature | -10℃~+50℃ | |||
DIMENSION | ||||
L×W×H (case base size) mm | 630*450*205 | 630*450*410 | 630*450*615 | 630*450*820 |
Weight(NK kg) | 45 kg | 90 kg | 135 kg | 180 kg |
AC Inverter output: | AC220V / 5 KW |
