SPS001

Plug and play solution, flexible expansion.

Hybrid Inverter with Solar Battery 15Kwh 22.5Kwh 30kwh Modular Stackable Batteries LiFePO4 Home energy Power Station

Inquiry

Download

Product Details

Hybrid Inverter with Solar Battery 15Kwh 22.5Kwh 30kwh Modular Stackable Batteries LiFePO4 Home energy Power Station

This home energy battery storage system has a flexible modular design that allows for stacking 2 to 5 battery modules. With available capacities from 16 KWH to 37.5 KWH, this power station system can be customized to meet a variety of needs. Additionally, this system comes with a high performance 10KW hybrid inverter, making it a truly all-in-one solution.

Advantage

: Plug and play solution, flexible expansion.

: Exclusively designed for residential ESS. Clear display system working status. Automatically intelligent management, no need for manual operation.

: With high performance cells and reliable systems, the design cycle life is up to 20 years.

: High voltage system means less discharge current, less heating, and more power to be conveyed to achieve high efficiency.

Product Parameters

Model	7.5 KWH	15KWH	22.5KWH	30KWH
Battery Type	LiFePO₄	LiFePO₄	LiFePO₄	LiFePO₄
Battery Module QTY(pcs)	1PCS	2PCS	3PCS	4PCS
Normal Capacity QTY(25℃,0.2C)	7.5 kwh	15 kwh	22.5kwh	30kwh
Rating voltage	51.2 V	51.2 V	51.2 V	51.2 V
Full charging voltage	58.4 V	58.4 V	58.4 V	58.4 V
Discharging stop voltage	41.6 V	41.6 V	41.6 V	41.6 V
Max charging current	100 A	100 A	100 A	100 A
MAX Discharging current	100 A	100 A	100 A	100 A
Cycle life	6000
Communication PORT	RS485/CAN
PROTECTION
Protection	Overcharge protection,Overdischarge protection,over load protection
working Temperature	-10℃~+50℃
DIMENSION
L×W×H (case base size) mm	670544200	670544400	670544600	670544800
Weight(NK kg)	78 kg	142 kg	206 kg	270 kg
AC Inverter output:	AC220V / 10KW
