NK01 All-in-one

Compatible with over 20 inverters. Multiple communication interfaces: RS485, RS232, CAN.

NK01/02 Floor-stand and Roller-type home energy storage system is the latest lithium battery design,  suitable for residential, office and small commercial purposes, convenient to move, and place anywhere!

Inquiry Download

Product Details

All-in-One system Solar power station

Floor Type home energy storage with AC inverter integrated

Flexible modular design

NK01/02 Floor-stand and Roller-type home energy storage system is the latest lithium battery design, suitable for residential, office and small commercial purposes, convenient to move, and place anywhere!

Advantage

Longer Lasting of 10-20 year Design Life.
Module level auto-balancing.
Compatible with over 20 inverters. Multiple communication interfaces: RS485, RS232, CAN.
Two models option for different requirements
AC Coupled for both new and retrofitted installations.
Reliable Built-In BMS, Voltage, Current, Temp, and Health Management.
Simple buckle fixing minimizes the installation time and cost.

Product Parameters

Model NumberNK01NK02
Battery typeLIFEPO4LIFEPO4
Rated voltage25.6 V51.2 V
Power5 Kwh10 kwh
Charging cut-off voltage29.2 V58.4 V
Discharge cut-off voltage20.8 V41.6 V
Recharging current100A100A
Discharging current150 A150 A
Communication portinternal communicationinternal communication
AC Inverter
Load Power3 KW5KW
DC input24 VDC48 VDC
MPPT60- 180Vdc,80A60- 180Vdc,80A
Ac input220Vac,50Hz220Vac,50Hz
Ac output220Vac,50Hz220Vac,50Hz
Product dimensionsL814*W550*H320mmL1016*W550*H320mm
Packing size924*671*515mm1126*671*515mm
Recharging working temperature0℃~45℃0℃~45℃

Discharge working temperature

-20℃~55℃-20℃~55℃
Net weight110 kg185 kg
Gross Weight125 kg205 kg
